FMSW6227

Part Number
FMSW6227
Manufacturer Fairview Microwave
Other Part Numbers
5328-FMSW6227-ND
5328-FMSW6227
Description PIN DIODE SWITCH 2.92MM SP3T 40G
Detailed Description RF Switch IC General Purpose SP3T 50Ohm
Manufacturer Standard Lead Time 2 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Fairview Microwave
Series
Packaging
Bag
Part Status Active
Impedance 50Ohm
Mounting Type Chassis Mount
Circuit SP3T
RF Type General Purpose
Operating Temperature -40°C ~ 85°C
Voltage - Supply -5V, 5V
Insertion Loss 5.5dB
Frequency Range 500MHz ~ 40GHz
Topology Reflective
Test Frequency 40GHz
Isolation 55dB (min)

Documents & Media

RESOURCE TYPE LINK
Datasheets FMSW6227

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
Moisture Sensitivity Level (MSL) 1 (Unlimited)
RoHS Status ROHS3 Compliant
