ESP32-C3FN4 _ RF Transceiver Modules and Modems_RF and Wireless

Part Number	ESP32-C3FN4
Manufacturer	Espressif Systems
Other Part Numbers	1904-ESP32-C3FN4TR-ND 1904-ESP32-C3FN4CT-ND 1904-ESP32-C3FN4DKR-ND 1904-ESP32-C3FN4DKR 1904-ESP32-C3FN4CT 1904-ESP32-C3FN4TR
Description	RF TXRX MODULE BLUETOOTH SMD
Detailed Description	Bluetooth, WiFi 802.11b/g/n, Bluetooth v5.0 Transceiver Module 2.402GHz ~ 2.48GHz Antenna Not Included Surface Mount
Datasheet	Datasheet

Category		RF and Wireless RF Transceiver Modules and Modems
Manufacturer		Espressif Systems
Series		ESP32
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Obsolete
Package / Case		32-VFQFN Exposed Pad
Sensitivity		-105dBm
Mounting Type		Surface Mount
Frequency		2.402GHz ~ 2.48GHz
Memory Size		4MB Flash, 400kB SRAM, 384kB ROM
Operating Temperature		-40°C ~ 85°C (TA)
Voltage - Supply		3V ~ 3.6V
Power - Output		21dBm
Data Rate		54Mbps
Protocol		802.11b/g/n, Bluetooth v5.0
Current - Receiving		84mA ~ 87mA
Current - Transmitting		276mA ~ 335mA
Antenna Type		Antenna Not Included
RF Family/Standard		Bluetooth, WiFi
Serial Interfaces		GPIO, I2C, I2S, SPI, JTAG, UART, USB
DigiKey Programmable		Not Verified

ATTRIBUTE		DESCRIPTION
ECCN		5A992C
HTSUS		8542.31.0001
Moisture Sensitivity Level (MSL)		3 (168 Hours)
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant

This product is no longer manufactured.
