ECS-200-18-4X-GM

ECS-200-18-4X-GM

Part Number	ECS-200-18-4X-GM
Manufacturer	ECS Inc. International
Other Part Numbers	50-ECS-200-18-4X-GM-ND 50-ECS-200-18-4X-GM
Description	CRYSTAL 20 MHZ 18PF SMD
Detailed Description	20 MHz ±30ppm Crystal 18pF 30 Ohms HC-49/US
Manufacturer Standard Lead Time	11 weeks
Datasheet	Datasheet

Product Attributes

Category		Crystals, Oscillators, Resonators Crystals
Manufacturer		ECS Inc. International
Series		HC-49USX
Packaging		Bulk
Part Status		Active
Package / Case		HC-49/US
Load Capacitance		18pF
Size / Dimension		0.447" L x 0.183" W (11.35mm x 4.65mm)
Mounting Type		Through Hole
Type		MHz Crystal
Operating Temperature		-20°C ~ 70°C
Frequency Stability		±30ppm
Frequency Tolerance		±30ppm
Operating Mode		Fundamental
Height - Seated (Max)		0.138" (3.50mm)
ESR (Equivalent Series Resistance)		30 Ohms
Frequency		20 MHz

Documents & Media

RESOURCE TYPE		LINK
Datasheets		ECS-200-18-4X-GM
Datasheets		Crystal Numbering Guide

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8541.60.0050
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

In Stock: 929

Can ship immediately.
