DSC1502AI3A-125M0000T

DSC1502AI3A-125M0000T

Part Number	DSC1502AI3A-125M0000T
Manufacturer	Roving Networks (Microchip Technology)
Other Part Numbers	150-DSC1502AI3A-125M0000T-ND 150-DSC1502AI3A-125M0000T
Description	MEMS OSC, LOW JITTER, 125MHZ, 2.
Detailed Description	125 MHz XO (Standard) LVCMOS Oscillator 2.25V ~ 3.63V Standby (Power Down) 4-VDFN Exposed Pad
Datasheet	Datasheet

Product Attributes

Category		Crystals, Oscillators, Resonators Oscillators
Manufacturer		Roving Networks (Microchip Technology)
Series		DSC150X
Packaging		Strip
Part Status		Active
Package / Case		4-VDFN Exposed Pad
Size / Dimension		0.276" L x 0.197" W (7.00mm x 5.00mm)
Mounting Type		Surface Mount
Output		LVCMOS
Function		Standby (Power Down)
Type		XO (Standard)
Operating Temperature		-40°C ~ 85°C
Frequency Stability		±20ppm
Voltage - Supply		2.25V ~ 3.63V
Current - Supply (Max)		7.5mA
Current - Supply (Disable) (Max)		1.8µA (Typ)
Height - Seated (Max)		0.035" (0.90mm)
Frequency		125 MHz
Base Resonator		MEMS

Documents & Media

RESOURCE TYPE		LINK
Datasheets		DSC1502AI3A-125M0000T

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8542.39.0001
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
