DS18S20Z+T&R

DS18S20Z+T&R

Part Number	DS18S20Z+T&R
Manufacturer	Maxim Integrated / Analog Devices
Other Part Numbers	DS18S20Z+T&RTR-ND DS18S20Z+T&RCT-ND DS18S20Z+T&RDKR-ND DS18S20Z+T&RCT DS18S20Z+T&R-ND DS18S20Z+T&RTR DS18S20Z+T&RDKR DS18S20ZTR
Description	SENSOR DIGITAL -55C-125C 8SOIC
Detailed Description	Temperature Sensor Digital, Local -55°C ~ 125°C 9 b 8-SOIC
Manufacturer Standard Lead Time	29 weeks
Datasheet	Datasheet

Product Attributes

Category		Sensors, Transducers Temperature Sensors Analog and Digital Output
Manufacturer		Maxim Integrated / Analog Devices
Series
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Features		Output Switch, Programmable Limit, Standby Mode
Package / Case		8-SOIC (0.154", 3.90mm Width)
Output Type		1-Wire®
Mounting Type		Surface Mount
Operating Temperature		-55°C ~ 125°C
Voltage - Supply		3V ~ 5.5V
Sensor Type		Digital, Local
Resolution		9 b
Supplier Device Package		8-SOIC
Test Condition		-10°C ~ 85°C (-55°C ~ 125°C)
Accuracy - Highest (Lowest)		±0.5°C (±2°C)
Sensing Temperature - Local		-55°C ~ 125°C
