DM74S08J

DM74S08J

Part Number	DM74S08J
Manufacturer	National Semiconductor
Other Part Numbers	2156-DM74S08J-ND 2156-DM74S08J NATNSCDM74S08J
Description	IC GATE AND 4CH 2-INP 14CDIP
Detailed Description	AND Gate IC 4 Channel 14-CDIP

Product Attributes

Category		Integrated Circuits (ICs) Logic Gates and Inverters
Manufacturer		National Semiconductor
Series		74S
Packaging		Bulk
Part Status		Active
Package / Case		14-CDIP (0.300", 7.62mm)
Mounting Type		Through Hole
Logic Type		AND Gate
Operating Temperature		0°C ~ 70°C
Voltage - Supply		4.75V ~ 5.25V
Current - Output High, Low		1mA, 20mA
Number of Inputs		2
Supplier Device Package		14-CDIP
Input Logic Level - High		2V
Input Logic Level - Low		0.8V
Max Propagation Delay @ V, Max CL		11ns @ 5V, 50pF
Number of Circuits		4
Current - Quiescent (Max)		57 mA
