DG509ACWE+

Part Number
DG509ACWE+
Manufacturer Maxim Integrated / Analog Devices
Other Part Numbers
DG509ACWE+-ND
-4941-DG509ACWE+
Description IC SWITCH SP4T X 2 450OHM 16SOIC
Detailed Description 2 Circuit IC Switch 4:1 450Ohm 16-SOIC
Manufacturer Standard Lead Time 16 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Maxim Integrated / Analog Devices
Series
Packaging
Tube
Part Status Active
Package / Case 16-SOIC (0.295", 7.50mm Width)
Mounting Type Surface Mount
Operating Temperature 0°C ~ 70°C (TA)
On-State Resistance (Max) 450Ohm
Supplier Device Package 16-SOIC
Voltage - Supply, Dual (V±) ±4.5V ~ 18V
Switch Circuit SP4T
Multiplexer/Demultiplexer Circuit 4:1
Channel-to-Channel Matching (ΔRon) 27Ohm
Switch Time (Ton, Toff) (Max) 1.5µs, 1µs
Channel Capacitance (CS(off), CD(off)) 5pF, 12pF
Current - Leakage (IS(off)) (Max) 1nA
Number of Circuits 2
