DCM251515H-683HF

DCM251515H-683HF

Part Number	DCM251515H-683HF
Manufacturer	ITG Electronics, Inc.
Other Part Numbers	3013-DCM251515H-683HF-ND 3013-DCM251515H-683HF
Description	68,000uH,1970mOhm,0.6Amp DIP CMC
Detailed Description	68 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 600mA DCR 1.97Ohm (Typ)
Datasheet	Datasheet

Product Attributes

Category		Filters Common Mode Chokes
Manufacturer		ITG Electronics, Inc.
Series		DCM251515H
Packaging		Bulk
Part Status		Active
Package / Case		Horizontal, 4 PC Pin
Filter Type		Power Line
Size / Dimension		0.965" L x 0.610" W (24.50mm x 15.50mm)
Mounting Type		Through Hole
Number of Lines		2
Operating Temperature		-55°C ~ 130°C
Height (Max)		0.551" (14.00mm)
Current Rating (Max)		600mA
DC Resistance (DCR) (Max)		1.97Ohm (Typ)
Inductance @ Frequency		68 mH @ 10 kHz

Documents & Media

RESOURCE TYPE		LINK
Datasheets		DCM251515H-683HF

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.50.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
