Part Number |
D151K20Y5PL63L6
|
---|---|
Manufacturer | Vishay BC Components |
Other Part Numbers |
1402PH-ND
2252 618 27111
D151K20Y5PLAAEU
1402PH-NDR
1402PH
|
Description | CAP CER 150PF 500V Y5P RADIAL |
Detailed Description | 150 pF ±10% 500V Ceramic Capacitor Y5P (B) Radial, Disc |
Datasheet | Datasheet |
Category | ||
---|---|---|
Manufacturer | Vishay BC Components | |
Series |
D
|
|
Packaging |
Bulk
|
|
Part Status | Obsolete | |
Tolerance | ±10% | |
Lead Style | Straight | |
Voltage - Rated | 500V | |
Package / Case | Radial, Disc | |
Temperature Coefficient | Y5P (B) | |
Size / Dimension | 0.197" Dia (5.00mm) | |
Mounting Type | Through Hole | |
Operating Temperature | -30°C ~ 125°C | |
Applications | General Purpose | |
Lead Spacing | 0.250" (6.35mm) | |
Height - Seated (Max) | 0.157" (4.00mm) | |
Capacitance | 150 pF |
RESOURCE TYPE | LINK | |
---|---|---|
Datasheets | D151K20Y5PL63L6 |
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8532.23.0060 | |
Moisture Sensitivity Level (MSL) | Not Applicable | |
REACH Status | REACH Unaffected | |
RoHS Status | RoHS non-compliant |
