Part Number |
CP2001-7R
|
---|---|
Manufacturer | Power-One (Bel Power Solutions) |
Other Part Numbers |
CP2001-7R-ND
|
Description | DC/DC CONVERTER 2X5.1V 182W |
Detailed Description | Enclosed, Conformal Coated DC DC Converter 2 Output 5.1V 5.1V 17.8A, 17.8A 75V Input |
Category | ||
---|---|---|
Manufacturer | Power-One (Bel Power Solutions) | |
Series |
Melcher P (90 ~ 192W)
|
|
Packaging |
-
|
|
Part Status | Obsolete | |
Power (Watts) | 182W | |
Size / Dimension | 6.73" L x 4.37" W x 0.78" H (171.0mm x 111.0mm x 19.8mm) | |
Mounting Type | Chassis Mount | |
Type | Enclosed, Conformal Coated | |
Operating Temperature | -25°C ~ 71°C | |
Applications | ITE (Commercial), Railway | |
Voltage - Input (Max) | 75V | |
Approval Agency | CE, CSA, EN, IEC, TUV, UL | |
Efficiency | 88% | |
Current - Output (Max) | 17.8A, 17.8A | |
Voltage - Input (Min) | 33.6V | |
Voltage - Output 1 | 5.1V | |
Voltage - Output 2 | 5.1V | |
Number of Outputs | 2 |
RESOURCE TYPE | LINK |
---|
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8504.40.9580 | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
REACH Status | REACH Unaffected | |
RoHS Status | RoHS non-compliant |
