CI3302P1V10 _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	CI3302P1V10
Manufacturer	CviLux
Other Part Numbers	2987-CI3302P1V10-ND 2987-CI3302P1V10
Description	CONN HEADER VERT 2POS 2.54MM
Detailed Description	Connector Header Through Hole 2 position 0.100" (2.54mm)
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		CviLux
Series		CI33
Packaging		Bag
Part Status		Active
Connector Type		Header
Voltage Rating		250VAC
Current Rating (Amps)		3A
Mounting Type		Through Hole
Number of Positions		2
Number of Rows		1
Style		Board to Cable/Wire
Operating Temperature		-40°C ~ 105°C
Contact Type		Male Pin
Fastening Type		Latch Holder
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Contact Material		Brass
Insulation Color		Black
Pitch - Mating		0.100" (2.54mm)
Contact Finish - Mating		Tin
Contact Finish Thickness - Mating		120.0µin (3.05µm)
Contact Finish - Post		Tin
Contact Shape		Square
Contact Length - Post		0.134" (3.40mm)
Insulation Height		0.453" (11.50mm)
Shrouding		Shrouded - 4 Wall
Insulation Material		Polyamide (PA), Nylon, Glass Filled

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
