CI1503M1VR0-NH _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	CI1503M1VR0-NH
Manufacturer	CviLux
Other Part Numbers	2987-CI1503M1VR0-NHTR-ND 2987-CI1503M1VR0-NHCT-ND 2987-CI1503M1VR0-NHCT 2987-CI1503M1VR0-NHTR
Description	3 POS 1.50MM(.059) WIRE TO BOARD
Detailed Description	Connector Header Surface Mount 3 position 0.059" (1.50mm)
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		CviLux
Series		CI15
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Features		Pick and Place, Solder Retention
Connector Type		Header
Voltage Rating		50VAC
Current Rating (Amps)		1A (AC/DC)
Mounting Type		Surface Mount
Number of Positions		3
Number of Rows		1
Style		Board to Cable/Wire
Operating Temperature		-25°C ~ 85°C
Contact Type		Male Pin
Fastening Type		Detent Lock
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Contact Material		Brass
Insulation Color		Natural
Pitch - Mating		0.059" (1.50mm)
Contact Finish - Mating		Tin
Contact Finish Thickness - Mating		120.0µin (3.05µm)
Contact Finish - Post		Tin
Contact Finish Thickness - Post		120.0µin (3.05µm)
Contact Shape		Square
Insulation Height		0.199" (5.05mm)
Shrouding		Shrouded - 4 Wall
Insulation Material		Plastic, Halogen Free
Contact Length - Mating		0.093" (2.36mm)

RESOURCE TYPE		LINK
Datasheets		CI1503M1VR0-NH

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
