CI1104M1HR0-NH _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	CI1104M1HR0-NH
Manufacturer	CviLux
Other Part Numbers	2987-CI1104M1HR0-NHTR-ND 2987-CI1104M1HR0-NHCT-ND 2987-CI1104M1HR0-NHCT 2987-CI1104M1HR0-NHTR
Description	4POS 1.00MM(.039) SINGLE ROW RIG
Detailed Description	Connector Header Surface Mount, Right Angle 4 position 0.039" (1.00mm)
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		CviLux
Series		CI11
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Features		Solder Retention
Connector Type		Header
Voltage Rating		50VAC
Current Rating (Amps)		1A (AC/DC)
Mounting Type		Surface Mount, Right Angle
Number of Positions		4
Number of Rows		1
Style		Board to Cable/Wire
Operating Temperature		-25°C ~ 85°C
Contact Type		Male Pin
Fastening Type		Detent Lock
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Contact Material		Phosphor Bronze
Insulation Color		Natural
Pitch - Mating		0.039" (1.00mm)
Contact Finish - Mating		Tin
Contact Finish Thickness - Mating		100.0µin (2.54µm)
Contact Finish - Post		Tin
Contact Finish Thickness - Post		100.0µin (2.54µm)
Contact Shape		Rectangular
Insulation Height		0.116" (2.95mm)
Shrouding		Shrouded - 4 Wall
Insulation Material		Polyamide (PA6T), Nylon 6T, Glass Filled, Halogen Free
Contact Length - Mating		0.069" (1.75mm)

RESOURCE TYPE		LINK
Datasheets		CI1104M1HR0-NH

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
