CFM-4020BF-035-114 _ DC Brushless Fans (BLDC)_Fans_Fans, Blowers, Thermal Management

Part Number	CFM-4020BF-035-114
Manufacturer	CUI Devices
Other Part Numbers	2223-CFM-4020BF-035-114-ND 2223-CFM-4020BF-035-114
Description	FAN AXIAL 40X20MM BALL 5VDC WIRE
Detailed Description	Fan Tubeaxial 5VDC Square - 40mm L x 40mm H Ball 4.4 CFM (0.123m³/min) 2 Wire Leads
Manufacturer Standard Lead Time	19 weeks

Category		Fans, Blowers, Thermal Management Fans DC Brushless Fans (BLDC)
Manufacturer		CUI Devices
Series		CFM-40BF
Packaging		Box
Part Status		Active
Features		Auto Restart
Voltage - Rated		5VDC
Size / Dimension		Square - 40mm L x 40mm H
Bearing Type		Ball
Current Rating (Amps)		0.060A
RPM		3500 RPM
Air Flow		4.4 CFM (0.123m³/min)
Width		20.00mm
Operating Temperature		14 ~ 158°F (-10 ~ 70°C)
Voltage Range		4.5 ~ 5.5VDC
Termination		2 Wire Leads
Approval Agency		CE, cURus, TUV
Lifetime @ Temp.		70000 Hrs @ 40°C
Fan Type		Tubeaxial
Noise		11.4dB(A)
Static Pressure		0.060 in H2O (14.9 Pa)
Material - Frame		Polybutylene Terephthalate (PBT)
Material - Blade		Polybutylene Terephthalate (PBT)
Power (Watts)		300 mW

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8414.59.6590
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
