CA3004P1300 _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	CA3004P1300
Manufacturer	CviLux
Other Part Numbers	2987-CA3004P1300-ND 2987-CA3004P1300
Description	1.27MM (.050) DIP TYPE MALE CONN
Detailed Description	Connector Header Through Hole 4 position 0.100" (2.54mm)
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		CviLux
Series		CA30
Packaging		Tube
Part Status		Active
Connector Type		Header
Voltage Rating		230VAC/DC
Current Rating (Amps)		1.5A
Mounting Type		Through Hole
Number of Positions		4
Number of Rows		2
Style		Board to Board or Cable
Operating Temperature		-40°C ~ 105°C
Contact Type		Male Pin
Fastening Type		Locking Ramp
Number of Positions Loaded		All
Termination		Kinked Pin, Solder
Material Flammability Rating		UL94 V-0
Contact Material		Phosphor Bronze
Insulation Color		Red
Pitch - Mating		0.100" (2.54mm)
Contact Finish - Mating		Tin
Contact Finish - Post		Tin
Contact Shape		Rectangular
Contact Length - Post		0.122" (3.10mm)
Insulation Height		0.267" (6.78mm)
Shrouding		Shrouded - 4 Wall
Insulation Material		Polyester, Glass Filled
Row Spacing - Mating		0.059" (1.50mm)

RESOURCE TYPE		LINK
Datasheets		CA3004P1300

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

Can ship immediately.
