Part Number |
BLED25W-043-C0580
|
---|---|
Manufacturer | Thomas Research Products (Current Lighting) |
Other Part Numbers |
1121-1539-ND
1121-1539
|
Description | LED DRIVER CC AC/DC 21-36V 700MA |
Detailed Description | 700mA 21 ~ 36V Constant Current LED Driver AC DC Converter Topology 1 Output |
Datasheet | Datasheet |
Category | ||
---|---|---|
Manufacturer | Thomas Research Products (Current Lighting) | |
Series |
BLED-25W
|
|
Packaging |
Box
|
|
Part Status | Obsolete | |
Size / Dimension | 3.44" L x 1.44" W x 0.94" H (87.5mm x 36.5mm x 24.0mm) | |
Voltage - Output | 21 ~ 36V | |
Mounting Type | Chassis Mount | |
Type | Constant Current | |
Weight | 0.282 lb (127.91 g) | |
Termination Style | Wire Leads | |
Voltage - Input (Max) | 305VAC | |
Approval Agency | cURus | |
Ratings | IP64 | |
Efficiency | 87% | |
Topology | AC DC Converter | |
Current - Output (Max) | 700mA | |
Voltage - Input (Min) | 90VAC | |
Power (Watts) | 25 W | |
Number of Outputs | 1 | |
DigiKey Programmable | Not Verified |
RESOURCE TYPE | LINK | |
---|---|---|
Datasheets | BLED25W-043-C0580 | |
Datasheets | DK OBS NOTICE |
ATTRIBUTE | DESCRIPTION | |
---|---|---|
California Prop 65 | California Prop 65 Information | |
ECCN | EAR99 | |
HTSUS | 8504.40.9510 | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
RoHS Status | RoHS Compliant |
