AWHW-200-20RP12 _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	AWHW-200-20RP12
Manufacturer	ASSMANN WSW Components
Other Part Numbers	123-AWHW-200-20RP12-ND 123-AWHW-200-20RP12
Description	DIN 41651 HEADER MALE THR 20PIN
Detailed Description	Connector Header Through Hole 20 position 0.079" (2.00mm)
Manufacturer Standard Lead Time	18 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		ASSMANN WSW Components
Series		AWHW
Packaging		Tray
Part Status		Active
Features		Keying Slot
Connector Type		Header
Current Rating (Amps)		1A
Mounting Type		Through Hole
Number of Positions		20
Number of Rows		2
Style		Board to Cable/Wire
Operating Temperature		-40°C ~ 105°C
Contact Type		Male Pin
Fastening Type		Latch Lock/Eject Hooks, Long
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Contact Material		Brass
Insulation Color		Black
Pitch - Mating		0.079" (2.00mm)
Contact Finish - Mating		Gold
Contact Finish Thickness - Mating		Flash
Contact Shape		Square
Contact Length - Post		0.126" (3.20mm)
Insulation Height		0.807" (20.50mm)
Shrouding		Shrouded - 4 Wall
Insulation Material		Polyamide (PA9T), Nylon 9T, Glass Filled
Row Spacing - Mating		0.079" (2.00mm)
Contact Length - Mating		0.142" (3.60mm)

RESOURCE TYPE		LINK
Datasheets		AWHW-200-20RP12

ATTRIBUTE		DESCRIPTION
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
