AW140-EG-Z11A _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	AW140-EG-Z11A
Manufacturer	ASSMANN WSW Components
Other Part Numbers	123-AW140-EG-Z11A-ND 123-AW140-EG-Z11A
Description	PIN HEADER, 6.1/3.8MM, 2.54MM, 1
Detailed Description	Connector Header Through Hole 11 position 0.100" (2.54mm)
Manufacturer Standard Lead Time	6 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		ASSMANN WSW Components
Series		AW140
Packaging		Bag
Part Status		Active
Connector Type		Header, Cuttable
Voltage Rating		250VAC/DC
Current Rating (Amps)		3A per Contact
Mounting Type		Through Hole
Number of Positions		11
Number of Rows		1
Style		Board to Board
Operating Temperature		-40°C ~ 105°C
Contact Type		Male Pin
Fastening Type		Push-Pull
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Contact Material		Brass
Insulation Color		Black
Pitch - Mating		0.100" (2.54mm)
Contact Finish - Mating		Tin
Contact Shape		Square
Contact Length - Post		0.150" (3.81mm)
Insulation Height		0.098" (2.50mm)
Shrouding		Unshrouded
Overall Contact Length		0.488" (12.40mm)
Insulation Material		Polybutylene Terephthalate (PBT)
Contact Length - Mating		0.240" (6.10mm)

RESOURCE TYPE		LINK
Datasheets		AW140-EG-Z11A

ATTRIBUTE		DESCRIPTION
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
