AT91SAM9M10-CU

Part Number
AT91SAM9M10-CU
Manufacturer Atmel (Microchip Technology)
Other Part Numbers
2156-AT91SAM9M10-CU-AT-ND
ATMATMAT91SAM9M10-CU
2156-AT91SAM9M10-CU-AT
Description IC MPU SAM9M 400MHZ 324TFBGA
Detailed Description ARM926EJ-S Microprocessor IC SAM9M 1 Core, 32-Bit 400MHz 324-TFBGA (15x15)

Product Attributes

Category
Manufacturer Atmel (Microchip Technology)
Series
SAM9M
Packaging
Tray
Part Status Obsolete
Package / Case 324-TFBGA
Mounting Type Surface Mount
Speed 400MHz
Operating Temperature -40°C ~ 85°C (TA)
Core Processor ARM926EJ-S
Voltage - I/O 1.8V, 3.3V
Supplier Device Package 324-TFBGA (15x15)
Ethernet 10/100Mbps
USB USB 2.0 (3)
Number of Cores/Bus Width 1 Core, 32-Bit
RAM Controllers LPDDR, LPSDR, DDR2, SDR, SRAM
Graphics Acceleration No
Display & Interface Controllers LCD, Touchscreen, Video Decoder
Additional Interfaces AC97, EBI/EMI, I2C, ISI, MMC/SD/SDIO, SPI, SSC, UART/USART

Documents & Media

RESOURCE TYPE LINK

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN 3A991A2
HTSUS 8542.31.0001
RoHS Status ROHS3 Compliant

Obsolete

This product is no longer manufactured.
