ASP0461022 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	ASP0461022
Manufacturer	RIA Connect / METZ CONNECT
Other Part Numbers	ASP0461022-ND
Description	SPRING CLAMP TERMINAL BLOCK, PLU
Detailed Description	10 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm) 180° Free Hanging (In-Line)
Manufacturer Standard Lead Time	18 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		RIA Connect / METZ CONNECT
Series
Packaging		Bulk
Part Status		Active
Features		Lever Actuated, Retention Latches (Non-Wire Side)
Color		Black
Mounting Type		Free Hanging (In-Line)
Number of Positions		10
Pitch		0.200" (5.08mm)
Type		Plug, Female Sockets
Operating Temperature		-40°C ~ 105°C
Termination Style		Screwless - Spring Cage, Tension Clamp
Number of Levels		1
Wire Gauge or Range - AWG		16-28 AWG
Wire Gauge or Range - mm²		0.08-1mm²
Positions Per Level		10
Plug Wire Entry		180°
Current - UL		10 A
Voltage - UL		300 V

RESOURCE TYPE		LINK
Datasheets		ASP0461022

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
