AN8011S-E1V

Part Number
AN8011S-E1V
Manufacturer Panasonic Electronic Components
Other Part Numbers
AN8011SE1VTR-ND
AN8011SE1
AN8011SE1CT
AN8011S-E1
AN8011SE1VTR
AN8011SE1TR
AN8011SE1CT-ND
AN8011SE1VCT
AN8011SE1TR-ND
AN8011SE1V
Description IC REG CTRLR BUCK/BOOST 16SO
Detailed Description Buck, Boost Regulator Positive or Negative Output Step-Up, Step-Down DC-DC Controller IC 16-SOP
Datasheet Datasheet

Product Attributes

Category
Manufacturer Panasonic Electronic Components
Series
Packaging
Tape & Reel (TR)
Part Status Obsolete
Package / Case 16-SOIC (0.173", 4.40mm Width)
Output Type Transistor Driver
Mounting Type Surface Mount
Function Step-Up, Step-Down
Operating Temperature -30°C ~ 85°C (TA)
Output Configuration Positive or Negative
Frequency - Switching 200kHz
Topology Buck, Boost
Voltage - Supply (Vcc/Vdd) 3.6V ~ 34V
Supplier Device Package 16-SOP
Synchronous Rectifier No
Control Features Dead Time Control, Enable, Frequency Control
Output Phases 1
Duty Cycle (Max) 45%, 75%
Clock Sync No
Number of Outputs 2

Documents & Media

RESOURCE TYPE LINK
Datasheets AN8011S-E1V

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8542.39.0001
Moisture Sensitivity Level (MSL) 1 (Unlimited)

Obsolete

This product is no longer manufactured.
