Part Number |
AN44180A-VF
|
---|---|
Manufacturer | Panasonic Electronic Components |
Other Part Numbers |
AN44180A-VF-ND
|
Description | IC MTR DRV BIPOLAR 0-5.5V 32SSOP |
Detailed Description | Bipolar Motor Driver Power MOSFET Parallel 32-SSOP |
Category | ||
---|---|---|
Manufacturer | Panasonic Electronic Components | |
Series | ||
Packaging |
Tape & Reel (TR)
|
|
Part Status | Obsolete | |
Package / Case | 32-SSOP (0.240", 6.10mm Width) | |
Mounting Type | Surface Mount | |
Function | Driver - Fully Integrated, Control and Power Stage | |
Current - Output | 1.5A | |
Interface | Parallel | |
Operating Temperature | -20°C ~ 120°C (TJ) | |
Output Configuration | Half Bridge (4) | |
Voltage - Supply | 0V ~ 5.5V | |
Applications | General Purpose | |
Technology | Power MOSFET | |
Voltage - Load | 8V ~ 34V | |
Supplier Device Package | 32-SSOP | |
Motor Type - Stepper | Bipolar | |
Step Resolution | 1, 1/2, 1/8, 1/16 |
RESOURCE TYPE | LINK |
---|
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8542.39.0001 | |
Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
RoHS Status | RoHS Compliant |
