AM6CW-11012DH22-NZ

AM6CW-11012DH22-NZ

Part Number	AM6CW-11012DH22-NZ
Manufacturer	Aimtec
Other Part Numbers	2721-AM6CW-11012DH22-NZ-ND 2721-AM6CW-11012DH22-NZ
Description	DC DC CONVERTER +/-12V 6W
Detailed Description	Isolated Module DC DC Converter 2 Output -5 ~ 5V -12V 40V - 160V Input
Datasheet	Datasheet

Product Attributes

Category		Power Supplies - Board Mount DC DC Converters
Manufacturer		Aimtec
Series		AM6CW-NZ (6W)
Packaging		Tube
Part Status		Active
Size / Dimension		1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm)
Mounting Type		Through Hole
Type		Isolated Module
Operating Temperature		-40°C ~ 85°C
Applications		ITE (Commercial)
Voltage - Input (Max)		160V
Approval Agency		CE, cULus, cURus
Efficiency		84%
Voltage - Input (Min)		40V
Voltage - Output 1		-5 ~ 5V
Voltage - Output 2		-12V
Power (Watts)		6 W
Number of Outputs		2

Documents & Media

RESOURCE TYPE		LINK
Datasheets		AM6CW-11012DH22-NZ

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.40.9580
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
