AM100QB-11005SA30JZ _ DC DC Converters_Power Supplies

Part Number	AM100QB-11005SA30JZ
Manufacturer	Aimtec
Other Part Numbers	2721-AM100QB-11005SA30JZ-ND 2721-AM100QB-11005SA30JZ
Description	100W DC/DC Converter
Detailed Description	Isolated Module DC DC Converter 1 Output 5V 20A 43V - 160V Input
Datasheet	Datasheet

Category		Power Supplies - Board Mount DC DC Converters
Manufacturer		Aimtec
Series		AM100QB-JZ
Packaging		Box
Part Status		Active
Features		Adjustable Output, Baseplate, Remote On/Off, Remote Sense
Package / Case		Quarter Brick
Size / Dimension		2.39" L x 1.54" W x 0.50" H (60.8mm x 39.2mm x 12.7mm)
Mounting Type		Through Hole
Type		Isolated Module
Operating Temperature		-40°C ~ 105°C
Applications		ITE (Commercial)
Voltage - Input (Max)		160V
Efficiency		88%
Current - Output (Max)		20A
Supplier Device Package		Quarter Brick
Voltage - Input (Min)		43V
Voltage - Output 1		5V
Power (Watts)		100 W
Number of Outputs		1
Voltage - Isolation		3 kV

RESOURCE TYPE		LINK
Datasheets		AM100QB-11005SA30JZ

ATTRIBUTE		DESCRIPTION
HTSUS		8504.40.9580
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH info available upon request
RoHS Status		ROHS3 Compliant
