AE320FF30PN-LC

Part Number
AE320FF30PN-LC
Manufacturer Conesys
Other Part Numbers
2403-AE320FF30PN-LC-ND
2403-AE320FF30PN-LC
Description CONN RCPT HSG MALE 30POS PNL MT
Detailed Description 30 Position Circular Connector Receptacle Housing Panel Mount
Datasheet Datasheet

Product Attributes

Category
Manufacturer Conesys
Series
MIL-DTL-38999 Series III
Packaging
Box
Part Status Active
Connector Type Receptacle Housing
Mounting Type Panel Mount
Shielding Shielded
Number of Positions 30
Type For Male Pins
Orientation N (Normal)
Shell Size - Insert F-30
Operating Temperature -65°C ~ 200°C
Contact Type Crimp
Fastening Type Threaded
Contact Size 16 (1), 20 (29)
Mounting Feature Flange
Note Contacts Not Included
Shell Material Aluminum
Shell Finish Nickel

Documents & Media

RESOURCE TYPE LINK
Datasheets AE320FF30PN-LC

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8536.69.4020
RoHS Status ROHS3 Compliant
