ADH40028

Part Number
ADH40028
Manufacturer Zettler Magnetics
Other Part Numbers
3388-ADH40028-ND
3388-ADH40028
Description PWR XFMR 6VA TH
Manufacturer Standard Lead Time 19 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Zettler Magnetics
Series
ADH400
Packaging
Tray
Part Status Active
Size / Dimension 41.30mm L x 33.30mm W
Mounting Type Through Hole
Termination Style PC Pin
Primary Winding(s) Dual, Multiple Taps
Secondary Winding(s) Dual, Multiple Taps
Power - Max 6VA
Voltage - Isolation 2500V
Current - Output (Max) Parallel 400mA, Series 200mA
Voltage - Primary 115V, 230V
Height - Seated (Max) 1.297" (32.95mm)
Voltage - Secondary (Full Load) Parallel 14V, Series 28V
Center Tap No

Documents & Media

RESOURCE TYPE LINK
Datasheets ADH40028

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.31.4035
Moisture Sensitivity Level (MSL) Not Applicable
REACH Status REACH Unaffected
RoHS Status ROHS3 Compliant

In Stock: 772

Can ship immediately.
