A6S-7104-H(VNM)

A6S-7104-H(VNM)

Part Number	A6S-7104-H(VNM)
Manufacturer	Omron Electronic Components
Other Part Numbers	39-A6S-7104-H(VNM)-ND A6S7104H A6S7104HVNM 39-A6S-7104-H(VNM) A6S-7104-H-ND A6S-7104-H Z12150-ND Z12150
Description	SWITCH SLIDE DIP SPST 0.025A 24V
Detailed Description	Dip Switch SPST 7 Position Surface Mount Slide (Standard) Actuator 25mA 24VDC
Manufacturer Standard Lead Time	14 weeks
Datasheet	Datasheet

Product Attributes

Category		Switches DIP Switches
Manufacturer		Omron Electronic Components
Series		A6S-H
Packaging		Tube
Part Status		Active
Contact Finish		Gold
Voltage Rating		24VDC
Current Rating (Amps)		25mA
Mounting Type		Surface Mount
Pitch		0.100" (2.54mm), Full
Circuit		SPST
Operating Temperature		-20°C ~ 70°C
Termination Style		Gull Wing
Actuator Type		Slide (Standard)
Height Above Board		0.173" (4.40mm)
Actuator Level		Raised
Washable		No
Number of Positions		7

Documents & Media

RESOURCE TYPE		LINK
Datasheets		A6S-7104-H(VNM)
Datasheets		How to Read Date Codes
Datasheets		Mult Dev COO/MPN CHgs Apr/2023
Datasheets		A6S Series Raised Actuator

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.50.9065
Moisture Sensitivity Level (MSL)		Not Applicable
RoHS Status		RoHS Compliant

In Stock: 441

Can ship immediately.
