805-113 _ Wire to Board_Terminal Blocks_Connectors, Interconnects

Part Number	805-113
Manufacturer	WAGO
Other Part Numbers	2946-805-113-ND 0805-0113 0805113 2943-805-113-ND 8050113 2943-805-113 805113 2946-805-113 0805-113
Description	PCB TERMINAL BLOCK; PUSH-BUTTON;
Detailed Description	13 Position Wire to Board Terminal Block Horizontal with Board 0.138" (3.50mm) Through Hole
Manufacturer Standard Lead Time	12 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Wire to Board
Manufacturer		WAGO
Series		805
Packaging		Box
Part Status		Active
Features		Push Button Actuated
Color		Gray
Mounting Type		Through Hole
Wire Gauge		16-24 AWG
Pitch		0.138" (3.50mm)
Operating Temperature		-60°C ~ 105°C
Mating Orientation		Horizontal with Board
Positions Per Level		13
Housing Material		Polyamide (PA66), Nylon 6/6
Contact Material - Plating		Electrolytic Copper - Tin Plated
Clamp Material - Plating		Steel - Nickel Plated
Wire Termination		Screwless - Push Button Clamp
Current		10 A
Number of Levels		1
Voltage		300 V

RESOURCE TYPE		LINK
Datasheets		805-113

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
