78604/1MC-R

78604/1MC-R

Part Number	78604/1MC-R
Manufacturer	Murata Power Solutions
Other Part Numbers	78604/1MC-R-ND
Description	PULSE XFMR 2:1 2MH
Detailed Description	2mH General Purpose Pulse Transformer 2:1 Surface Mount
Datasheet	Datasheet

Product Attributes

Category		Transformers Pulse Transformers
Manufacturer		Murata Power Solutions
Series		786
Packaging		Tape & Reel (TR)
Part Status		Not For New Designs
Inductance		2mH
Size / Dimension		0.375" L x 0.354" W (9.52mm x 9.00mm)
Mounting Type		Surface Mount
Operating Temperature		0°C ~ 70°C
Transformer Type		General Purpose
Turns Ratio - Primary:Secondary		2:1
ET (Volt-Time)		20VµS
Height - Seated (Max)		0.250" (6.35mm)

Documents & Media

RESOURCE TYPE		LINK
Datasheets		78604/1MC-R

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.31.2000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Affected
RoHS Status		ROHS3 Compliant

Available To Order

Not recommended for new design, minimums may apply.
