77209C

Part Number
77209C
Manufacturer Murata Power Solutions
Other Part Numbers
77209C-ND
Description PULSE XFMR 2:1:1 16.3MH
Detailed Description 16.3mH SCR and Triac Trigger (Encapsulated) Pulse Transformer 2:1:1 Through Hole
Manufacturer Standard Lead Time 15 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Murata Power Solutions
Series
Packaging
Tube
Part Status Active
Inductance 16.3mH
Size / Dimension 1.000" L x 0.799" W (25.40mm x 20.30mm)
Mounting Type Through Hole
Operating Temperature 0°C ~ 70°C
Transformer Type SCR and Triac Trigger (Encapsulated)
Turns Ratio - Primary:Secondary 2:1:1
ET (Volt-Time) 482VµS
Height - Seated (Max) 0.484" (12.30mm)

Documents & Media

RESOURCE TYPE LINK
Datasheets 77209C

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.31.2000
Moisture Sensitivity Level (MSL) Not Applicable
REACH Status REACH Unaffected
RoHS Status ROHS3 Compliant
