713-1423 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	713-1423
Manufacturer	WAGO
Other Part Numbers	2946-713-1423-ND 2943-713-1423-ND 2943-713-1423 7131423 2946-713-1423 0713-1423 07131423
Description	THT MALE HEADER, 2-ROW; 0.8 X 0.
Detailed Description	6 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.138" (3.50mm) 90°, Right Angle Through Hole
Manufacturer Standard Lead Time	12 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		WAGO
Series		MCSMINI HD
Packaging		Box
Part Status		Active
Color		Black
Mounting Type		Through Hole
Number of Positions		6
Pitch		0.138" (3.50mm)
Type		Header, Male Pins, Shrouded (4 Side)
Operating Temperature		-60°C ~ 100°C
Termination Style		Solder
Material Flammability Rating		UL94 V-0
Current - IEC		10A
Number of Levels		2
Positions Per Level		3
Contact Material		Electrolytic Copper
Header Orientation		90°, Right Angle
Housing Material		Polyphthalamide (PPA), Glass Filled
Contact Mating Finish		Tin
Contact Tail Length		0.150" (3.81mm)
Insulation Height		0.524" (13.30mm)
Current - UL		10 A
Voltage - IEC		250 V
Voltage - UL		150 V

RESOURCE TYPE		LINK
Datasheets		713-1423

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
