31030122 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	31030122
Manufacturer	RIA Connect / METZ CONNECT
Other Part Numbers	31030122-ND
Description	SHROUDED HEADER, RIGHT ANGLE, PC
Detailed Description	22 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.197" (5.00mm) 90°, Right Angle Through Hole
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		RIA Connect / METZ CONNECT
Series
Packaging		Bulk
Part Status		Active
Color		Black
Mounting Type		Through Hole
Number of Positions		22
Pitch		0.197" (5.00mm)
Type		Header, Male Pins, Shrouded (4 Side)
Operating Temperature		-40°C ~ 105°C
Termination Style		Solder
Material Flammability Rating		UL94 V-0
Number of Levels		1
Positions Per Level		22
Contact Material		Copper Zinc
Header Orientation		90°, Right Angle
Housing Material		Polyamide (PA66), Nylon 6/6
Contact Mating Finish		Silver
Contact Tail Length		0.142" (3.60mm)
Insulation Height		0.327" (8.30mm)
Current - UL		15 A
Voltage - UL		300 V

RESOURCE TYPE		LINK
Datasheets		31030122

ATTRIBUTE		DESCRIPTION
California Prop 65		California Prop 65 Information
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
