2734-220 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	2734-220
Manufacturer	WAGO
Other Part Numbers	2946-2734-220-ND 2734220 2946-2734-220 02734-220 02734220 60257699 2943-2734-220 2943-2734-220-ND 2734-0220
Description	1-CONDUCTOR FEMALE PLUG; 100% PR
Detailed Description	20 Position Terminal Block Plug, Female Sockets 0.150" (3.81mm) 180° Free Hanging (In-Line)
Manufacturer Standard Lead Time	12 weeks

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		WAGO
Series		MCSMINI
Packaging		Box
Part Status		Active
Features		Retention Latches (Non-Wire Side)
Color		Orange
Mounting Type		Free Hanging (In-Line)
Number of Positions		20
Pitch		0.150" (3.81mm)
Type		Plug, Female Sockets
Operating Temperature		-60°C ~ 100°C
Termination Style		Screwless - Push-In Spring
Current - IEC		10A
Number of Levels		1
Wire Gauge or Range - AWG		16-24 AWG
Wire Gauge or Range - mm²		0.2-1.5mm²
Positions Per Level		20
Plug Wire Entry		180°
Contact Mating Finish		Tin
Current - UL		10 A
Voltage - IEC		320 V
Voltage - UL		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
RoHS Status		ROHS3 Compliant
