2706-305 _ Wire to Board_Terminal Blocks_Connectors, Interconnects

Part Number	2706-305
Manufacturer	WAGO
Other Part Numbers	2946-2706-305-ND 2706305 02706305 2706-0305 2943-2706-305 27060305 2943-2706-305-ND 02706-305 2946-2706-305
Description	PCB TERMINAL BLOCK; LEVER; 6 MM;
Detailed Description	5 Position Wire to Board Terminal Block Horizontal with Board 0.492" (12.50mm) Through Hole
Manufacturer Standard Lead Time	12 weeks

Category		Connectors, Interconnects Terminal Blocks Wire to Board
Manufacturer		WAGO
Series		2706
Packaging		Box
Part Status		Active
Features		Lever Actuated
Color		Gray
Mounting Type		Through Hole
Wire Gauge		10-20 AWG
Pitch		0.492" (12.50mm)
Operating Temperature		-60°C ~ 105°C
Mating Orientation		Horizontal with Board
Positions Per Level		5
Housing Material		Polyamide (PA66), Nylon 6/6
Contact Material - Plating		Electrolytic Copper - Tin Plated
Clamp Material - Plating		Steel - Nickel Plated
Wire Termination		Screwless - Spring Cage, Tension Clamp
Current		30 A
Number of Levels		1
Voltage		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
