2606-1106/020-000 _ Wire to Board_Terminal Blocks_Connectors, Interconnects

Part Number	2606-1106/020-000
Manufacturer	WAGO
Other Part Numbers	2946-2606-1106/020-000-ND 60331706 02606-1106/020-000 2606-1106/0020-0000 026061106/020000 2946-2606-1106/020-000 2943-2606-1106/020-000 26061106/020000 2943-2606-1106/020-000-ND
Description	PCB TERMINAL BLOCK; LEVER; 6 MM;
Detailed Description	6 Position Wire to Board Terminal Block Horizontal with Board 0.295" (7.50mm) Through Hole
Manufacturer Standard Lead Time	12 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Wire to Board
Manufacturer		WAGO
Series		2606
Packaging		Box
Part Status		Active
Features		Lever Actuated
Color		Gray
Mounting Type		Through Hole
Wire Gauge		8-24 AWG
Pitch		0.295" (7.50mm)
Operating Temperature		-60°C ~ 105°C
Mating Orientation		Horizontal with Board
Positions Per Level		6
Housing Material		Polyamide (PA66), Nylon 6/6
Contact Material - Plating		Electrolytic Copper - Tin Plated
Clamp Material - Plating		Steel - Nickel Plated
Wire Termination		Screwless - Spring Cage, Tension Clamp
Current		31 A
Number of Levels		1
Voltage		600 V

RESOURCE TYPE		LINK
Datasheets		2606-1106/020-000

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
