24S180C

Part Number
24S180C
Manufacturer Murata Power Solutions
Other Part Numbers
24S180C-ND
Description FIXED IND 18UH 1.22A 91MOHM SMD
Detailed Description 18 µH Shielded Wirewound Inductor 1.22 A 91mOhm Max Nonstandard
Manufacturer Standard Lead Time 12 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Murata Power Solutions
Series
2400
Packaging
Tape & Reel (TR)
Part Status Active
Package / Case Nonstandard
Size / Dimension 0.303" L x 0.280" W (7.70mm x 7.10mm)
Mounting Type Surface Mount
Shielding Shielded
Type Wirewound
Operating Temperature -40°C ~ 85°C
DC Resistance (DCR) 91mOhm Max
Frequency - Self Resonant 23MHz
Inductance Frequency - Test 1 kHz
Height - Seated (Max) 0.177" (4.50mm)
Inductance 18 µH
Current Rating (Amps) 1.22 A

Documents & Media

RESOURCE TYPE LINK
Datasheets 2400 Series Datasheet

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.50.4000
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
RoHS Status ROHS3 Compliant
