2383217-3 _ Modular Connector Plugs_Modular Connectors_Connectors, Interconnects

Part Number	2383217-3
Manufacturer	TE Connectivity AMP Connectors
Other Part Numbers	17-2383217-3-ND 17-2383217-3
Description	RJ45 FIELD INSTALLABLE CABLE CON
Detailed Description	Plug Modular Connector 8p8c (RJ45, Ethernet) Position Shielded Cat5e IDC
Manufacturer Standard Lead Time	27 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Modular Connectors Modular Connector Plugs
Manufacturer		TE Connectivity AMP Connectors
Series
Packaging		Box
Part Status		Active
Features		Angled (90°), Cover
Connector Type		Plug
Contact Finish		Gold
Color		Orange
Shielding		Shielded
Number of Positions/Contacts		8p8c (RJ45, Ethernet)
Cable Type		Round Cable, Solid or Stranded Wires
Termination		IDC
Ingress Protection		IP20
Ratings		Cat5e
Contact Finish Thickness		30.0µin (0.76µm)
Shield Material		Copper, Zinc Alloy
Contact Material		Copper Alloy
Housing Material		Polyamide (PA), Nylon
Current Rating (Amps)		1.5 A

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.8000
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
