231-381/001-000 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	231-381/001-000
Manufacturer	WAGO
Other Part Numbers	2946-231-381/001-000-ND 2943-231-381/001-000 0231381/001000 51152616 2943-231-381/001-000-ND 0231-381/001-000 2946-231-381/001-000 231381/001000 0231-0381/0001-0000
Description	THT MALE HEADER; 1.2 X 1.2 MM SO
Detailed Description	21 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.200" (5.08mm) Vertical Through Hole
Manufacturer Standard Lead Time	12 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		WAGO
Series		MCSMIDI Classic
Packaging		Box
Part Status		Active
Color		Orange
Mounting Type		Through Hole
Number of Positions		21
Pitch		0.200" (5.08mm)
Type		Header, Male Pins, Shrouded (4 Side)
Operating Temperature		-60°C ~ 100°C
Termination Style		Solder
Material Flammability Rating		UL94 V-0
Current - IEC		16A
Number of Levels		1
Positions Per Level		21
Contact Material		Electrolytic Copper
Header Orientation		Vertical
Housing Material		Polyamide (PA66), Nylon 6/6
Contact Mating Finish		Tin
Contact Tail Length		0.197" (5.00mm)
Insulation Height		0.472" (12.00mm)
Current - UL		15 A
Voltage - IEC		630 V
Voltage - UL		600 V

RESOURCE TYPE		LINK
Datasheets		231-381/001-000

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
