2092-1730 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	2092-1730
Manufacturer	WAGO
Other Part Numbers	2946-2092-1730-ND 2943-2092-1730-ND 2946-2092-1730 2943-2092-1730 02092-1730 20921730 020921730 60418351
Description	SOLDER PIN STRIP 1.4 MM SOLDER
Detailed Description	10 Position Terminal Block Header, Male Pins, Partial Shroud 0.197" (5.00mm) 90°, Right Angle Through Hole
Manufacturer Standard Lead Time	12 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		WAGO
Series		picoMAX® 5.0
Packaging		Bag
Part Status		Active
Color		Black
Mounting Type		Through Hole
Number of Positions		10
Pitch		0.197" (5.00mm)
Type		Header, Male Pins, Partial Shroud
Operating Temperature		-60°C ~ 100°C
Termination Style		Solder
Material Flammability Rating		UL94 V-0
Current - IEC		16A
Number of Levels		1
Positions Per Level		10
Contact Material		Electrolytic Copper
Header Orientation		90°, Right Angle
Housing Material		Polyphthalamide (PPA), Glass Filled
Contact Mating Finish		Tin
Contact Tail Length		0.142" (3.60mm)
Insulation Height		0.295" (7.50mm)
Voltage - IEC		630 V

RESOURCE TYPE		LINK
Datasheets		2092-1730

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
