Part Number |
1901-220V
|
---|---|
Manufacturer | B&K Precision |
Other Part Numbers |
BK1901-220V-ND
BK1901 EXD
BK1901-220V
1901 EXD
BK1901 EXD-ND
|
Description | PWR SPLY 1-32V 30A SW DC 220V-IN |
Detailed Description | 1 ~ 32VDC Output Bench (AC to DC) Power Supply LED 0 ~ 30A Output Features Adjustable or Fixed Selection Switch |
Category | ||
---|---|---|
Manufacturer | B&K Precision | |
Series |
1900
|
|
Packaging |
Box
|
|
Part Status | Obsolete | |
Features | Adjustable or Fixed Selection Switch | |
Display Type | LED | |
Size / Dimension | 10.800" L x 7.900" W x 3.500" H (274.32mm x 200.66mm x 88.90mm) | |
Voltage - Output | 1 ~ 32VDC | |
Number of Characters | 3 (2) | |
Current - Output | 0 ~ 30A | |
Type | Bench (AC to DC) | |
Voltage - Supply | 230VAC | |
Number of Outputs | 1 |
RESOURCE TYPE | LINK |
---|
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8504.40.9540 | |
Moisture Sensitivity Level (MSL) | Not Applicable | |
REACH Status | REACH Unaffected | |
RoHS Status | Not applicable |
