1800984 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	1800984
Manufacturer	Phoenix Contact
Other Part Numbers	1800984-ND MSTBV 2 5/17-GF-5 08 BK
Description	HEADER NOMINAL CURRENT: 12 A NUM
Detailed Description	17 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.200" (5.08mm) Vertical Through Hole
Manufacturer Standard Lead Time	6 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		Phoenix Contact
Series		COMBICON MSTBVA
Packaging		Bulk
Part Status		Active
Color		Black
Mounting Type		Through Hole
Number of Positions		17
Pitch		0.200" (5.08mm)
Type		Header, Male Pins, Shrouded (4 Side)
Termination Style		Solder
Current - IEC		12A
Number of Levels		1
Positions Per Level		17
Header Orientation		Vertical
Contact Mating Finish		Tin
Contact Tail Length		0.154" (3.90mm)
Insulation Height		0.472" (12.00mm)
Current - UL		12 A
Voltage - IEC		250 V
Voltage - UL		300 V

RESOURCE TYPE		LINK
Datasheets		1800984

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		RoHS Compliant
