1764980000

1764980000

Part Number	1764980000
Manufacturer	Weidmuller
Other Part Numbers	1764980000-ND LM3RZF/5.08/135/33 LM3RZF 5.08/33/135 3.5SN OR BX 2266-1862760000 1764980000-NDR
Description	TERM BLK 11POS 45DEG 5.08MM PCB
Detailed Description	11 Position Wire to Board Terminal Block 45° (135°) Angle with Board 0.200" (5.08mm) Through Hole
Manufacturer Standard Lead Time	27 weeks
Datasheet	Datasheet

Product Attributes

Category		Connectors, Interconnects Terminal Blocks Wire to Board
Manufacturer		Weidmuller
Series		Omnimate LMZF
Packaging		Bulk
Part Status		Active
Color		Orange
Mounting Type		Through Hole
Wire Gauge		14-24 AWG
Pitch		0.200" (5.08mm)
Operating Temperature		-50°C ~ 100°C
Mating Orientation		45° (135°) Angle with Board
Positions Per Level		11
Housing Material		Polyamide (PA), Nylon
Contact Material - Plating		Copper Alloy - Tin Plated
Wire Termination		Screwless - Spring Cage, Tension Clamp
Current		10 A
Number of Levels		3
Voltage		300 V

Documents & Media

RESOURCE TYPE		LINK
Datasheets		1764980000

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
