1689160000 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	1689160000
Manufacturer	Weidmuller
Other Part Numbers	281-1270-ND BLZF 5.08/2 281-1270 168916 281-1270-NDR
Description	TERM BLOCK PLUG 2POS STR 5.08MM
Detailed Description	2 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm) 180° Free Hanging (In-Line)

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		Weidmuller
Series		Omnimate BL
Packaging		Bulk
Part Status		Obsolete
Features		Retention Latches (Non-Wire Side)
Color		Black
Mounting Type		Free Hanging (In-Line)
Number of Positions		2
Pitch		0.200" (5.08mm)
Type		Plug, Female Sockets
Operating Temperature		-50°C ~ 130°C
Termination Style		Screwless - Spring Cage, Tension Clamp
Material Flammability Rating		UL94 V-0
Current - IEC		12A
Number of Levels		1
Wire Gauge or Range - AWG		12-22 AWG
Wire Gauge or Range - mm²		2.5mm²
Positions Per Level		2
Contact Material		Copper Alloy
Plug Wire Entry		180°
Housing Material		Polybutylene Terephthalate (PBT)
Contact Mating Finish		Tin
Wire Strip Length		7mm
Insulation Height		0.500" (12.70mm)
Current - UL		10 A
Voltage - IEC		125 V
Voltage - UL		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected

This product is no longer manufactured.
