1610150000 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	1610150000
Manufacturer	Weidmuller
Other Part Numbers	1610150000-ND 1610150000-NDR SL 3.5 180 6 BK
Description	TERM BLOCK HDR 6POS VERT 3.5MM
Detailed Description	6 Position Terminal Block Header, Male Pins, Shrouded (2 Side) 0.138" (3.50mm) Vertical Through Hole

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		Weidmuller
Series		Omnimate SL
Packaging		Bulk
Part Status		Obsolete
Color		Black
Mounting Type		Through Hole
Number of Positions		6
Pitch		0.138" (3.50mm)
Type		Header, Male Pins, Shrouded (2 Side)
Operating Temperature		-20°C ~ 100°C
Termination Style		Solder
Material Flammability Rating		UL94 V-0
Current - IEC		12A
Number of Levels		1
Positions Per Level		6
Contact Material		Copper Alloy
Header Orientation		Vertical
Housing Material		Polybutylene Terephthalate (PBT)
Contact Mating Finish		Tin
Contact Tail Length		0.177" (4.50mm)
Insulation Height		0.437" (11.10mm)
Current - UL		10 A
Voltage - IEC		125 V
Voltage - UL		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected

This product is no longer manufactured.
