08025SE-24R-FT-DW _ DC Brushless Fans (BLDC)_Fans_Fans, Blowers, Thermal Management

Part Number	08025SE-24R-FT-DW
Manufacturer	PMDM
Other Part Numbers	12-08025SE-24R-FT-DW-ND 12-08025SE-24R-FT-DW 08025SE24RFTDW
Description	FAN AXIAL 80X25MM 24VDC WIRE
Detailed Description	Fan Tubeaxial 24VDC Square - 80mm L x 80mm H Ball 60.0 CFM (1.68m³/min) 3 Wire Leads
Manufacturer Standard Lead Time	22 weeks
Datasheet	Datasheet

Category		Fans, Blowers, Thermal Management Fans DC Brushless Fans (BLDC)
Manufacturer		PMDM
Series		08025SE
Packaging		Bulk
Part Status		Active
Features		Auto Restart, Speed Sensor (Tach)
Voltage - Rated		24VDC
Size / Dimension		Square - 80mm L x 80mm H
Bearing Type		Ball
Current Rating (Amps)		0.170A
RPM		4500 RPM
Air Flow		60.0 CFM (1.68m³/min)
Width		25.00mm
Operating Temperature		14 ~ 140°F (-10 ~ 60°C)
Voltage Range		12 ~ 26.4VDC
Termination		3 Wire Leads
Approval Agency		CE, cULus, VDE
Ingress Protection		IP55 - Dust Protected, Water Resistant
Lifetime @ Temp.		40000 Hrs @ 60°C
Fan Type		Tubeaxial
Noise		42.0dB(A)
Static Pressure		0.329 in H2O (82.0 Pa)
Material - Frame		Plastic
Material - Blade		Plastic
Power (Watts)		4.08 W

RESOURCE TYPE		LINK
Datasheets		08025SE-24R-FT-DW

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8414.59.6590
Moisture Sensitivity Level (MSL)		Not Applicable
