0402DC-4N8XJRW _ Fixed Inductors_Inductors, Coils, Chokes

Part Number	0402DC-4N8XJRW
Manufacturer	COILCRAFT
Other Part Numbers	2457-0402DC-4N8XJRW-ND 2457-0402DC-4N8XJRW
Description	FIXED IND 4.8NH 1.85A 48MOHM SM
Detailed Description	4.8 nH Unshielded Wirewound Inductor 1.85 A 48mOhm Max 0402 (1005 Metric)
Datasheet	Datasheet

Category		Inductors, Coils, Chokes Fixed Inductors
Manufacturer		COILCRAFT
Series		0402DC
Packaging		Tape & Reel (TR)
Part Status		Active
Tolerance		±5%
Package / Case		0402 (1005 Metric)
Size / Dimension		0.044" L x 0.026" W (1.11mm x 0.66mm)
Mounting Type		Surface Mount
Shielding		Unshielded
Type		Wirewound
Operating Temperature		-40°C ~ 125°C
DC Resistance (DCR)		48mOhm Max
Q @ Freq		67 @ 900MHz
Frequency - Self Resonant		12.45GHz
Ratings		AEC-Q200
Material - Core		Ceramic
Inductance Frequency - Test		250 MHz
Supplier Device Package		0402
Height - Seated (Max)		0.026" (0.65mm)
Inductance		4.8 nH
Current Rating (Amps)		1.85 A

RESOURCE TYPE		LINK
Datasheets		0402DC-4N8XJRW
