EEH-AZK1V181B _ Aluminum - Polymer Capacitors_Capacitors

Part Number	EEH-AZK1V181B
Manufacturer	Panasonic Electronic Components
Other Part Numbers	10-EEH-AZK1V181BCT-ND 10-EEH-AZK1V181BTB-ND 10-EEH-AZK1V181BTB EEHAZK1V181B 10-EEH-AZK1V181BCT
Description	CAP ALUM POLY HYB 180UF 35V T/H
Detailed Description	180 µF 35 V Aluminum - Polymer Capacitors Radial, Can 27mOhm 4000 Hrs @ 125°C
Manufacturer Standard Lead Time	15 weeks
Datasheet	Datasheet

Category		Capacitors Aluminum - Polymer Capacitors
Manufacturer		Panasonic Electronic Components
Series		ZK
Packaging		Cut Tape (CT) Tape & Box (TB)
Part Status		Active
Tolerance		±20%
Package / Case		Radial, Can
Size / Dimension		0.315" Dia (8.00mm)
Mounting Type		Through Hole
Type		Hybrid
Operating Temperature		-55°C ~ 125°C
Applications		Automotive
Lead Spacing		0.138" (3.50mm)
Ratings		AEC-Q200
ESR (Equivalent Series Resistance)		27mOhm
Lifetime @ Temp.		4000 Hrs @ 125°C
Height - Seated (Max)		0.413" (10.50mm)
Capacitance		180 µF
Voltage - Rated		35 V
Ripple Current @ Low Frequency		300 mA @ 100 Hz
Ripple Current @ High Frequency		2 A @ 100 kHz

RESOURCE TYPE		LINK
Datasheets		EEH-AZK1V181B

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8532.22.0020
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
