Mfr Part #	Quantity	Price	Series	Package	Product Status	Tolerance	Features	Package / Case	Size / Dimension	Mounting Type	Type	Operating Temperature	Lead Spacing	Ratings	ESR (Equivalent Series Resistance)	Lifetime @ Temp.	Manufacturer Size Code	Height - Seated (Max)	Capacitance	Voltage - Rated
T598B225M050ATE200 CAP TANT POLY 2.2UF 50V 1411 TOKIN (KEMET) Datasheet	7,782 In Stock	2,000 : $820.00 4,000 : $1,600.00 10,000 : $3,800.00 14,000 : $5,180.00 Tape & Reel (TR)	KO-CAP® T598	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	Automotive	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 125°C	-	AEC-Q200	200mOhm @ 100kHz	2000 Hrs @ 125°C	B	0.083" (2.10mm)	2.2 µF	50 V
T529P226M010AAE150 CAP TANT POLY 22UF 10V 0805 TOKIN (KEMET) Datasheet	6,400 In Stock	3,000 : $1,530.00 6,000 : $2,940.00 9,000 : $4,230.00 15,000 : $6,900.00 Tape & Reel (TR)	KO-CAP® T529	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	0805 (2012 Metric)	0.079" L x 0.049" W (2.00mm x 1.25mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	150mOhm @ 100kHz	1000 Hrs @ 105°C	P	0.039" (1.00mm)	22 µF	10 V
T543X476K035ATE060 CAP TANT POLY 47UF 35V 2917 TOKIN (KEMET) Datasheet	947 In Stock	500 : $4,055.00 1,000 : $7,630.00 Tape & Reel (TR)	KO-CAP® T543	Tape & Reel (TR) Cut Tape (CT)	Active	±10%	High Reliability	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	60mOhm @ 100kHz	2000 Hrs @ 125°C	X	0.169" (4.30mm)	47 µF	35 V
T597S476M006APE200 CAP TANT POLY 47UF 6.3V 1206 TOKIN (KEMET) Datasheet	2,974 In Stock	3,000 : $990.00 Tape & Reel (TR)	KO-CAP® T597	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	Automotive	1206 (3216 Metric)	0.126" L x 0.063" W (3.20mm x 1.60mm)	Surface Mount	Molded	-55°C ~ 125°C	-	AEC-Q200	200mOhm @ 100kHz	2000 Hrs @ 125°C	-	0.047" (1.20mm)	47 µF	6.3 V
T598B476M006ATE070 CAP TANT POLY 47UF 6.3V 1411 TOKIN (KEMET) Datasheet	390 In Stock	2,000 : $780.00 Tape & Reel (TR)	KO-CAP® T598	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	Automotive	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 125°C	-	AEC-Q200	70mOhm @ 100kHz	2000 Hrs @ 125°C	B	0.083" (2.10mm)	47 µF	6.3 V
T521D685M050ATE090 CAP TANT POLY 6.8UF 50V 2917 TOKIN (KEMET) Datasheet	3,000 In Stock	500 : $580.00 1,000 : $1,010.00 2,500 : $2,450.00 5,000 : $4,700.00 Tape & Reel (TR)	KO-CAP® T521	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	-	90mOhm @ 100kHz	2000 Hrs @ 125°C	D	0.122" (3.10mm)	6.8 µF	50 V
T520A226M010ANE080 CAP TANT POLY 22UF 10V 1206 TOKIN (KEMET) Datasheet	1,537 In Stock	2,000 : $1,460.00 4,000 : $2,800.00 10,000 : $6,900.00 14,000 : $9,380.00 Tape & Reel (TR)	KO-CAP® T520	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	1206 (3216 Metric)	0.126" L x 0.063" W (3.20mm x 1.60mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	80mOhm @ 100kHz	2000 Hrs @ 105°C	A	0.071" (1.80mm)	22 µF	10 V
T521X107M025AHE060 100.UF 25.0V TOKIN (KEMET) Datasheet	622 In Stock	500 : $2,060.00 1,000 : $3,820.00 2,500 : $9,350.00 Tape & Reel (TR)	KO-CAP® T521	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	60mOhm @ 100kHz	2000 Hrs @ 105°C	X	0.169" (4.30mm)	100 µF	25 V
T543X686K025AHE035 68.0UF 25.0V TOKIN (KEMET) Datasheet	500 In Stock	500 : $2,330.00 1,000 : $4,320.00 Tape & Reel (TR)	KO-CAP® T543	Tape & Reel (TR) Cut Tape (CT)	Active	±10%	High Reliability	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	35mOhm	2000 Hrs @ 125°C	X	0.169" (4.30mm)	68 µF	25 V
T598B157M006ATE045 CAP TANT POLY 150UF 6.3V 1411 TOKIN (KEMET) Datasheet	2,635 In Stock	2,000 : $840.00 4,000 : $1,640.00 10,000 : $3,900.00 14,000 : $5,460.00 Tape & Reel (TR)	KO-CAP® T598	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	Automotive	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 125°C	-	AEC-Q200	45mOhm @ 100kHz	2000 Hrs @ 125°C	B	0.083" (2.10mm)	150 µF	6.3 V
