Mfr Part #	Quantity	Price	Series	Package	Product Status	Tolerance	Features	Package / Case	Size / Dimension	Mounting Type	Type	Operating Temperature	Lead Spacing	Ratings	ESR (Equivalent Series Resistance)	Lifetime @ Temp.	Manufacturer Size Code	Height - Seated (Max)	Capacitance	Voltage - Rated
T540D475M063AH6510 CAP TANT POLY 4.7UF 63V 2917 TOKIN (KEMET) Datasheet	1,016 In Stock	500 : $5,200.00 1,000 : $9,770.00 Tape & Reel (TR)	KO-CAP® T540	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	High Reliability	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	120mOhm @ 100kHz	-	D	0.122" (3.10mm)	4.7 µF	63 V
T529P226M006AAE200 CAP TANT POLY 22UF 6.3V 0805 TOKIN (KEMET) Datasheet	8,000 In Stock	3,000 : $1,230.00 6,000 : $2,400.00 9,000 : $3,420.00 15,000 : $5,550.00 Tape & Reel (TR)	KO-CAP® T529	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	0805 (2012 Metric)	0.079" L x 0.049" W (2.00mm x 1.25mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	200mOhm @ 100kHz	-	P	0.039" (1.00mm)	22 µF	6.3 V
T550B107M010AT4251 CAP TANT POLY 100UF 10V AXIAL TOKIN (KEMET) Datasheet	0 In Stock	20 : $988.60 Bulk	T550	Bulk	Active	±20%	General Purpose	Axial	0.281" Dia x 0.641" L (7.14mm x 16.28mm)	Through Hole	Hermetically Sealed	-55°C ~ 105°C	-	-	-	2000 Hrs @ 85°C	B	-	100 µF	10 V
T550B187M010AT4251 CAP TANT POLY 180UF 10V AXIAL TOKIN (KEMET) Datasheet	0 In Stock	20 : $988.60 Bulk	T550	Bulk	Active	±20%	General Purpose	Axial	0.281" Dia x 0.641" L (7.14mm x 16.28mm)	Through Hole	Hermetically Sealed	-55°C ~ 105°C	-	-	-	2000 Hrs @ 85°C	B	-	180 µF	10 V
T550B687M008AH4250 CAP TANT POLY 680UF 8V AXIAL TOKIN (KEMET) Datasheet	0 In Stock	40 : $1,195.60 Bulk	T550	Bulk	Active	±20%	General Purpose	Axial	0.281" Dia x 0.641" L (7.14mm x 16.28mm)	Through Hole	Hermetically Sealed	-55°C ~ 105°C	-	-	-	2000 Hrs @ 85°C	B	-	680 µF	8 V
T550B687M008AT4251 CAP TANT POLY 680UF 8V AXIAL TOKIN (KEMET) Datasheet	0 In Stock	20 : $988.60 Bulk	T550	Bulk	Active	±20%	General Purpose	Axial	0.281" Dia x 0.641" L (7.14mm x 16.28mm)	Through Hole	Hermetically Sealed	-55°C ~ 105°C	-	-	-	2000 Hrs @ 85°C	B	-	680 µF	8 V
T550B706M015AT4251 CAP TANT POLY 70UF 15V AXIAL TOKIN (KEMET) Datasheet	0 In Stock	20 : $988.60 Bulk	T550	Bulk	Active	±20%	General Purpose	Axial	0.281" Dia x 0.641" L (7.14mm x 16.28mm)	Through Hole	Hermetically Sealed	-55°C ~ 105°C	-	-	-	2000 Hrs @ 85°C	B	-	70 µF	15 V
T550B127K015AH CAP TANT POLY 120UF 15V AXIAL TOKIN (KEMET) Datasheet	0 In Stock	40 : $1,156.40 Bulk	T550	Bulk	Active	±10%	General Purpose	Axial	0.281" Dia x 0.641" L (7.14mm x 16.28mm)	Through Hole	Hermetically Sealed	-55°C ~ 105°C	-	-	-	2000 Hrs @ 85°C	B	-	120 µF	15 V
T550B687K008AH CAP TANT POLY 680UF 8V AXIAL TOKIN (KEMET) Datasheet	0 In Stock	40 : $1,156.40 Bulk	T550	Bulk	Active	±10%	General Purpose	Axial	0.281" Dia x 0.641" L (7.14mm x 16.28mm)	Through Hole	Hermetically Sealed	-55°C ~ 105°C	-	-	-	2000 Hrs @ 85°C	B	-	680 µF	8 V
T550B506M025AH CAP TANT POLY 50UF 25V AXIAL TOKIN (KEMET) Datasheet	0 In Stock	40 : $1,101.60 Bulk	T550	Bulk	Active	±20%	General Purpose	Axial	0.281" Dia x 0.641" L (7.14mm x 16.28mm)	Through Hole	Hermetically Sealed	-55°C ~ 105°C	-	-	-	2000 Hrs @ 85°C	B	-	50 µF	25 V
