PACKAGING	QUANTITY	UNIT PRICE	EXT PRICE
{{ p.name }}	{{ numberFormat(p.buyQty) }}	{{ priceFormat(p.unitPrice) }}	{{ priceFormat(p.totalPrice) }}
Total Amount: {{ priceFormat(quotes.total) }} (including {{ priceFormat(quotes.fee) }} fee)

Mfr Part #	Quantity	Price	Series	Package	Product Status	Tolerance	Features	Package / Case	Size / Dimension	Mounting Type	Type	Operating Temperature	Lead Spacing	Ratings	ESR (Equivalent Series Resistance)	Lifetime @ Temp.	Manufacturer Size Code	Height - Seated (Max)	Capacitance	Voltage - Rated
T540D477M2R5BH86057610 CAP TANT POLY 470UF 2.5V 2917 TOKIN (KEMET) Datasheet	0 In Stock	750 : $7,365.00 Bulk	KO-CAP® T540	Bulk	Active	±20%	High Reliability	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	40mOhm @ 100kHz	2000 Hrs @ 125°C	D	0.122" (3.10mm)	470 µF	2.5 V
T540D477M2R5CH87057610 CAP TANT POLY 470UF 2.5V 2917 TOKIN (KEMET) Datasheet	0 In Stock	750 : $8,895.00 Bulk	KO-CAP® T540	Bulk	Active	±20%	High Reliability	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	40mOhm @ 100kHz	2000 Hrs @ 125°C	D	0.122" (3.10mm)	470 µF	2.5 V
T540D687K2R5AH85057610 CAP TANT POLY 680UF 2.5V 2917 TOKIN (KEMET) Datasheet	0 In Stock	750 : $6,630.00 Bulk	KO-CAP® T540	Bulk	Active	±10%	High Reliability	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	40mOhm @ 100kHz	2000 Hrs @ 125°C	D	0.122" (3.10mm)	680 µF	2.5 V
T540D687M2R5AH85057610 CAP TANT POLY 680UF 2.5V 2917 TOKIN (KEMET) Datasheet	0 In Stock	750 : $5,887.50 Bulk	KO-CAP® T540	Bulk	Active	±20%	High Reliability	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	40mOhm @ 100kHz	2000 Hrs @ 125°C	D	0.122" (3.10mm)	680 µF	2.5 V
T540D687K2R5DH87057610 CAP TANT POLY 680UF 2.5V 2917 TOKIN (KEMET) Datasheet	0 In Stock	750 : $10,260.00 Bulk	KO-CAP® T540	Bulk	Active	±10%	High Reliability	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	40mOhm @ 100kHz	2000 Hrs @ 125°C	D	0.122" (3.10mm)	680 µF	2.5 V
T540B157K003DH85107610 CAP TANT POLY 150UF 3V 1411 TOKIN (KEMET) Datasheet	0 In Stock	3,600 : $31,032.00 Bulk	KO-CAP® T540	Bulk	Active	±10%	High Reliability	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	80mOhm @ 100kHz	2000 Hrs @ 125°C	B	0.083" (2.10mm)	150 µF	3 V
T540D687M2R5CH86057610 CAP TANT POLY 680UF 2.5V 2917 TOKIN (KEMET) Datasheet	0 In Stock	750 : $7,905.00 Bulk	KO-CAP® T540	Bulk	Active	±20%	High Reliability	2917 (7343 Metric)	0.287" L x 0.169" W (7.30mm x 4.30mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	40mOhm @ 100kHz	2000 Hrs @ 125°C	D	0.122" (3.10mm)	680 µF	2.5 V
T540B107K003DH86107610 CAP TANT POLY 100UF 3V 1411 TOKIN (KEMET) Datasheet	0 In Stock	3,600 : $35,496.00 Bulk	KO-CAP® T540	Bulk	Active	±10%	High Reliability	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	80mOhm @ 100kHz	2000 Hrs @ 125°C	B	0.083" (2.10mm)	100 µF	3 V
T540B107M003AH87107610 CAP TANT POLY 100UF 3V 1411 TOKIN (KEMET) Datasheet	0 In Stock	3,600 : $30,744.00 Bulk	KO-CAP® T540	Bulk	Active	±20%	High Reliability	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	80mOhm @ 100kHz	2000 Hrs @ 125°C	B	0.083" (2.10mm)	100 µF	3 V
T540B157M003BH86107610 CAP TANT POLY 150UF 3V 1411 TOKIN (KEMET) Datasheet	0 In Stock	3,600 : $28,008.00 Bulk	KO-CAP® T540	Bulk	Active	±20%	High Reliability	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 125°C	-	COTS	80mOhm @ 100kHz	2000 Hrs @ 125°C	B	0.083" (2.10mm)	150 µF	3 V
